Min. Agindua:1 Piece/Pieces
Marka: Risinglcd
produktibitatea: 1250k
Jatorria: Shenzhen
Ziurtagiri: CE/ROSH/UL/ISO9001
Shenzhen RisingStar 10.1 hazbeteko 1000 nit TFT LCD Panela, AUO / BOE / INNOLUX LCD modulua, LCD panelarekin duen lotura nagusia paneleko interfazearekin konektatuta dago paneleko errenkadaren bidez. LCD panel ezberdinek interfaze forma desberdinak erabiltzen dituzte. RisingStar 10,1 hazbeteko 1000 Nits TFT LCD panela batez ere LVDS interfazea da.
Mindurakin
| Size | 10.1inch |
| Panel item | RS101NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 350-1000cd/m2 |
| Constrast Ratio | 800:1 |
| Response Time | 14/11ms |
| View angle | 85/85/85/85 |
| View area | 218.96*137.6mm(H*V) |
| Dispaly area | 218.96*137.6mm(H*V) |
| Outline Size | 230.7*152.55*7mm(H*V*D) |
| Signal Type | LVDS |
| Working freqyency | 60Hz |
| Working temperature | -20~70ﾟC |
| Storage Temperature | -25~70ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Backlight Power Consumption | 6.18w |
| Surface Treatment | Haze |
| Weight | 0.375kgs |
