Min. Agindua:1 Piece/Pieces
Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Tamaina txikiko kapsulatutako kanpoko pantailak, 10,1 hazbeteko TFT 1000 Nits LCD monitorea. Pantailan agertzen den edukia ondo argiztatutako ingurunean ikus daiteke, karga pila, auto-zerbitzua saltzeko makinak, kioskoak eta zerbitzari terminalak mota guztiekin erabil daitezke.
Beste beharrak badituzu, jar zaitez gurekin harremanetan, zure beharren arabera kristal likidoen bistaratzeko irtenbide egokiena pertsonalizatuko dugu.
Kapsulatutako kanpoko bistaratze produktuen funtzioa
10.1 "TFT LCD panela
1280 * 800 bereizmena
Kanpokoa erabilita, 500nits-tik 1500 nits aukerakoa da
Ukipen-panel kapaziboa, 2mm tenplatutako beirazko solidoarekin estalita eta fidagarria Vandal frogarako
VGA HDMI DVI USB interfazea
Errendimendu handiko mainboarda, 7/24 Etengabeko eragiketa
Laguntza 12-24V zabaleko tentsio zabala
Bezela 3mm aurrean dagoen aurrealdeko muturreko mehea, muntatzeko kapsulatzeko aproposa
Aurreko panela IP55 iragazgaitza hautsaren prebentzioa
Tenperatura zabaleko funtzionamendua: -10 - 50 ° C
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
